DIN EN ISO 4957
1.2343 X37CrMoV5-1
AISI /SAE JIS GOST GB
H11 SKD6 4X5МФС 4Cr5MoSiV
Chemical Composition
C% | Si% | Mn% | P%≤ | S%≤ | Cr% | Mo% | V% |
0.33-0.41 | 0.80-1.20 | 0.25-0.50 | 0.030 | 0.030 | 4.80-5.50 | 1.10-1.50 | 0.30-0.50 |
Steel Properties
Molybdenum high speed tool steel.Very high resistance to softening at elevated temperatures.Very high resistance to wear.Good toughness and cutting capability.Deep hardening response.
Applications
Tools with a broad range of working hardness up to tool working temp.500 degree. Tools for hot forging of light metals. Pressure die casting tools,dies,mandrels,punchers, knives, and molds.
Heat Treatment
Annealing: 760 – 780 °C
Stress Relief Annealing: 600 - 650°C
Hardening:: 1010 – 1030 °C
Tempering: 540 – 560 °
